Описание

This device contains four independent 2-input XNOR Gates with open-drain outputs. Each gate performs the Boolean function Y = A ⊕ B in positive logic.

Wide Operating Voltage Range: 2 V to 6 V
Outputs Can Drive Up To 10 LSTTL Loads
Low Power Consumption, 20-µA Maximum I_CC
Typical t_pd = 8 ns at 5 V
±4-mA Output Drive at 5 V
Low Input Current of 1 µA

Technology family	HC
Number of channels	4
Inputs per channel	2
IOL (max) (mA)	5.2
Input type	Standard CMOS
IOH (max) (mA)	0
Output type	Open-drain
Features	High speed (tpd 10- 50ns)
Data rate (max) (MBits)	28
Rating	Catalog
Operating temperature range (°C)	-40 to 85
