Описание

The TUSB8040A1 is a four-port USB 3.0 compliant hub and is available in a 100-pin WQFN package. The device is designed for operation over the commercial temperature range of 0°C to 70°C. The TUSB8040A1 provides simultaneous SuperSpeed USB and high-speed or full-speed connections on the upstream port and provides SuperSpeed USB, high-speed, full-speed, or low-speed connections on the downstream ports. When the upstream port is connected to an electrical environment that only supports high-speed, full-speed, or low-speed connections, SuperSpeed USB connectivity is disabled on the downstream ports. When the upstream port is connected to an electrical environment that only supports full-speed or low-speed connections, SuperSpeed USB and high-speed connectivity are disabled on the downstream ports. The TUSB8040A1 supports up to four downstream ports. The device may be configured to report one to four downstream ports by pin selection or by an attached EEPROM or SMBus controller. The configuration options provide the ability to scale the device by application.

USB 3.0 Compliant Hub, TID #330000037
- Upstream Port Supports SuperSpeed USB,
  High-Speed and Full-Speed Connections
- Supports Four Downstream Ports
- Each of the Four Downstream Ports Support
  SuperSpeed USB, High-Speed, Full-Speed, or
  Low-Speed Connections
USB 2.0 Hub Features
- Multiple Transaction Translator (MTT) Hub: Four
  Transaction Translators, One Per Port
- Four Asynchronous Endpoint Buffers Per
  Transaction Translator (TT) for Better
  Throughput Than the USB-Required Minimum
  of Two Buffers Per TT
Supports Battery Charging Applications
- Battery Charging 1.2 Charging Downstream Port
  (CDP) When Upstream Port is Connected
- Battery Charging 1.2 and Chinese
  Telecommunications Industry Standard YD/T
  1591-2009 Dedicated Charging Port (DCP)
  When Upstream Port Is Disconnected
Supports Operation as a USB 3.0 or USB 2.0
Compound Device
Supports Per Port or Ganged Power Switching
and Overcurrent Notification Inputs
Provides the Following Status Outputs:
- High-Speed Upstream Connection
- High-Speed Upstream Port Suspended
- SuperSpeed USB Upstream Connection
- SuperSpeed USB Upstream Port Suspended
Optional Serial EEPROM or SMBus Slave
Interface for Custom Configurations:
- VID or PID
- Manufacturer and Product Strings
- Serial Number
Using Pin Selection or EEPROM and SMBus
Slave Interface, Each Downstream Port Can
Be Independently:
- Enabled or Disabled
- Marked as Removable or Permanently Attached
  (for Compound Applications)
- Have Battery Charging Enabled or Disabled
Provides 128-Bit Universally Unique Identifier (UUID)
Optionally Supports USB 2.0 Compliant Port
Indicator LEDs
Configurable SMBus Address to Support Multiple Devices
on the Same SMBus Segment
Supports Onboard and In-System EEPROM Programming
Through the USB 2.0 Upstream Port
Single Clock Input, 24-MHz Crystal or Oscillator
No Special Driver Requirements; Works Seamlessly With
Any Operating System With USB Stack Support

Function	USB3
USB speed (MBits)	5000
Type	Hub
Supply voltage (V)	1.1, 3.3
Rating	Catalog
Operating temperature range (°C)	0 to 70
