Описание

The TAS5760M-Q1 is a stereo digital input Class-D audio amplifier which is ideal for use in automotive emergency call (eCall), telematics, acoustic vehicle alerting system (AVAS) and EV/HEV sound generation applications. The device provides up to 25 W instantaneous power into 4 Ω at 10% THD+N at 14.4 V. The TAS5760M-Q1 also includes hardware and software (I²C) control modes, an integrated digital clipper, selectable gain options, and a wide power supply operating range (4.5 V – 26.4 V).An optimal mix of thermal performance and device cost is provided in the 120-mΩ RDS(ON) of the output MOSFETs.The device is offered in a thermally enhanced 32-Pin HTSSOP (DAP) package.

Qualified for Automotive Applications
- Temperature grade 1: –40°C to +125°C
Minimum Supply Voltage down to 4.5 V
Adjustable Switching Frequencies
Selectable Hardware or Software Control
Audio Performance (PVDD = 12 V, R_SPK = 8 Ω, SPK_GAIN[1:0] Pins = 00)
- Idle Channel Noise = 66 µVrms (A-Wtd)
- THD+N = 0.02% (at 1 W, 1 kHz)
- SNR = 99.7 dB A-Wtd (Ref. to THD+N = 1%)
Audio I/O Configuration:
- Single Stereo I²S Input
- Stereo Bridge Tied Load (BTL) or Mono Parallel Bridge Tied Load (PBTL) Operation
- 32, 44.1, 48, 88.2, 96 kHz Sample Rates
General Operational Features:
- Integrated Digital Output Clipper
- Programmable I²C Address (1101100[^R/_W] or 1101101[^R/_W])
- Closed-Loop Amplifier Architecture
Robustness Features:
- Clock Error, DC, and Short-Circuit Protection
- Overtemperature and Programmable Overcurrent Protection

Audio input type	Digital Input
Architecture	Class-D
Speaker channels (max)	Stereo
Rating	Automotive
Power stage supply (max) (V)	26.4
Power stage supply (min) (V)	4.5
Load (min) (Ω)	4
Output power (W)	25
SNR (dB)	100
THD + N at 1 kHz (%)	0.02
Iq (typ) (mA)	33
Control interface	Hardware, Software
Closed/open loop	Closed
Analog supply (min) (V)	4.5
Analog supply (max) (V)	26.4
Sampling rate (max) (kHz)	96
PSRR (dB)	80
Operating temperature range (°C)	-40 to 105
