Описание

The LM185 are micropower 3-terminal adjustable band-gap voltage reference diodes. Operating from 1.24 to 5.3V and over a 10μA to 20mA current range, they feature exceptionally low dynamic impedance and good temperature stability. On-chip trimming is used to provide tight voltage tolerance. Since the LM185 band-gap reference uses only transistors and resistors, low noise and good long-term stability result. Careful design of the LM185 has made the device tolerant of capacitive loading, making it easy to use in almost any reference application. The wide dynamic operating range allows its use with widely varying supplies with excellent regulation. The extremely low power drain of the LM185 makes it useful for micropower circuitry. This voltage reference can be used to make portable meters, regulators or general purpose analog circuitry with battery life approaching shelf life. Further, the wide operating current allows it to replace older references with a tighter tolerance part.

Adjustable from 1.24V to 5.30V
Operating Current of 10μA to 20mA
1Ω Dynamic Impedance
Low Temperature Coefficient

All trademarks are the property of their respective owners.

VO (V)	1.24
Initial accuracy (max) (%)	1
VO adj (min) (V)	1.24
VO adj (max) (V)	5.3
Iz for regulation (min) (µA)	10
Reference voltage (V)	Adjustable
Rating	Military
Operating temperature range (°C)	-55 to 125
Iout/Iz (max) (mA)	20
