Описание

The REF31xx-Q1 is a family of precision, low power, low dropout, series voltage references available in the tiny 3-pin SOT-23 package.The REF31xx-Q1 small size and low power consumption (100 µA typical) make it ideal for portable and battery-powered applications. The REF31xx-Q1 does not require a load capacitor, but is stable with any capacitive load and can sink or source up to 10 mA of output current.Unloaded, the REF31xx-Q1 can operate on supplies down to 5 mV above the output voltage. All models are specified for the wide temperature range of –40°C to +125°C.

AEC-Q100 Qualified With the Following Results:
- Device T_A Range: –40°C to 125°C
- Device HBM ESD Classification Level H1C
- Device CDM ESD Classification Level C4A
High Accuracy: 0.2% Maximum
Excellent Specified Drift Performance:
- 20 ppm/°C (Maximum) from –40°C to +125°C
High Output Current: ±10 mA
Low Dropout: 5 mV
Low I_Q: 115 µA Maximum
Low Noise: 17 µVp-p/V
No Output Capacitor Required
Available Voltage Options : 1.2 V, 2 V, 2.5 V, 3 V, 3.3 V, 4 V
MicroSize Package: 3-Pin SOT-23

VO (V)	1.25, 2.048, 2.5, 3, 3.3, 4.096
Initial accuracy (max) (%)	0.2
Temp coeff (max) (ppm/°C)	20
Vin (min) (V)	1.8
Vin (max) (V)	5.5
Iq (typ) (mA)	0.1
Rating	Automotive
TI functional safety category	Functional Safety-Capable
LFN 0.1 to 10 Hz (typ) (µVPP)	17, 27, 33, 39, 43, 53
Iout/Iz (max) (mA)	10
Operating temperature range (°C)	-40 to 125
