Описание

The REF2125 device is a low temperature drift (6 ppm/°C), low-power, high-precision CMOS voltage reference, featuring ±0.05% initial accuracy, low operating current with power consumption less than 95 µA. This device also offers very low output noise of 5 µVp-p /V, which enables its ability to maintain high signal integrity with high-resolution data converters and noise critical systems. Stability and system reliability are further improved by the low output-voltage hysteresis of the device and low long-term output voltage drift. Furthermore, the small size and low operating current of the devices (95 µA) make them ideal for portable and battery-powered applications. REF2125 is specified for the wide temperature range of −40°C to +125°C. Contact the TI sales representative for additional voltage options.

Initial Accuracy: ±0.05% (maximum)
Temperature Coefficient : 6 ppm/°C (maximum)
Operating Temperature Range: −40°C to +125°C
Output Current: ±10 mA
Low Quiescent Current: 95 µA (maximum)
Wide Input Voltage: 12 V
Output 1/f Noise (0.1 Hz to 10 Hz): 5 µV_PP/V
Excellent Long-Term Stability 30 ppm/1000 hrs
Small Footprint 5-Pin SOT-23 Package

VO (V)	2.5
Initial accuracy (max) (%)	0.05
Temp coeff (max) (ppm/°C)	6
Vin (min) (V)	2.55
Vin (max) (V)	12
Iq (typ) (mA)	0.072
Rating	Catalog
Features	Clean-start
LFN 0.1 to 10 Hz (typ) (µVPP)	5
Iout/Iz (max) (mA)	10
Operating temperature range (°C)	-40 to 125
Shutdown current (ISD) (typ) (µA)	1
