Описание

The TPS53632G device is a half-bridge PWM controller with D-CAP+ architecture that provides fast transient response, lowest outputcapacitance and high efficiency in single stage conversion directly from 48-V bus. The TPS53632G device supports the standard I2C Rev 3.0 interface for dynamic controlof the output voltage and current monitor telemetry. Paired with TI GaN power stages and drivers,the TPS53632G can switch up to 1 MHz to minimize magnetic component size and reduce overall boardspace. The LMG5200 GaN power stage is designed specifically for this controller to achieve highfrequency and efficiency as high as 92% with 48-V to 1-V conversion. Other features include adjustable control of output slew rate and voltage positioning. Inaddition, the TPS53632G device can be used along with other TI discrete power MOSFETs and driversfor silicon-based half bridge solutions. The TPS53632G device is packaged in a space saving,thermally enhanced, 32-pin VQFN package and is rated to operate at a range between –10°C and105°C.

Valley Current Mode with Constant ON Time Control
Lossless Current Sensing Scheme
I²C Interface for VID Control and Telemetry
Programmable I²C Addresses up to Eight Devices
Switching Frequency up to 1 MHz
Digital Current Monitor
7-Bit, DAC Output Range: 0.50-V to 1.52-V with 10-mV Step
Accurate, Adjustable Voltage Positioning or Zero Slope Load-Line
Selectable, 8-Level Current Limit
Adjustable Output Slew Rate Control
Default Boot Voltage: 1.00 V
Small, 4-mm × 4-mm, 32-Pin, VQFN, PowerPAD Package

Topology	Half bridge
Control mode	Current
Duty cycle (max) (%)	50
Switching frequency (max) (kHz)	2000
Features	Light-load efficiency
UVLO thresholds on/off (V)	2.8/2.6
Operating temperature range (°C)	-10 to 105
Rating	Catalog
Vin (max) (V)	3.6
