Описание

The TLV07 device is a 36-V, single-supply, low-noise, precision operational amplifier (op amp) manufactured using TI’s laser trim operational amplifier technology. Each amplifiers input offset voltage is trimmed in production to obtain a low offset voltage of 100 µV (maximum).The TLV07 offers outstanding dc precision and ac performance, including rail-to-rail output, low offset voltage (±100 µV, maximum) and 1-MHz bandwidth. The TLV07 is stable at G = 1 with capacitive loads up to 200 pF. The input can operate 100 mV below the negative rail and within 2 V of the positive rail. This wide input voltage range, combined with a high CMRR of 120 dB, make the TLV07 well-suited when operated in the non-inverting configuration.The TLV07 op amp is specified from –40°C to +125°C.

Low Offset Voltage: 100 µV (Maximum)
Rail-to-Rail Output
Low Noise: 19 nV / √Hz
Unity-Gain Stable
RFI Filtered Inputs
Input Range Includes Negative Supply
Rail-to-Rail Output
Gain Bandwidth: 1 MHz
Low Quiescent Current: 930 µA
Full Industrial Temperature Range:
–40°C to +125°C
Offered in the Industry-Standard 8-Pin SOIC Package

Number of channels	1
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	36
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	2.7
Vos (offset voltage at 25°C) (max) (mV)	0.1
GBW (typ) (MHz)	1
Features	Cost Optimized, EMI Hardened
Slew rate (typ) (V/µs)	0.4
Rail-to-rail	In to V-, Out
Offset drift (typ) (µV/°C)	0.9
Iq per channel (typ) (mA)	0.93
Vn at 1 kHz (typ) (nV√Hz)	19
CMRR (typ) (dB)	120
Rating	Catalog
Operating temperature range (°C)	-40 to 125
Iout (typ) (A)	0.017
Architecture	CMOS
Input common mode headroom (to negative supply) (typ) (V)	-0.1
Input common mode headroom (to positive supply) (typ) (V)	-2
Output swing headroom (to negative supply) (typ) (V)	0.12
Output swing headroom (to positive supply) (typ) (V)	-0.12
