Описание

The LM675 is a monolithic power operational amplifier featuring wide bandwidth and low input offset voltage, making it equally suitable for AC and DC applications. The LM675 is capable of delivering output currents in excess of 3 amps, operating at supply voltages of up to 60V. The device overload protection consists of both internal current limiting and thermal shutdown. The amplifier is also internally compensated for gains of 10 or greater.

3A Current Capability
A_VO Typically 90 dB
5.5 MHz Gain Bandwidth Product
8 V/μs Slew Rate
Wide Power Bandwidth 70 kHz
1 mV Typical Offset Voltage
Short Circuit Protection
Thermal Protection with Parole Circuit (100% Tested)
16V–60V Supply Range
Wide Common Mode Range
Internal Output Protection Diodes
90 dB Ripple Rejection
Plastic Power Package TO-220

All trademarks are the property of their respective owners.

Number of channels	1
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	10
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	60
Iout (typ) (A)	4
GBW (typ) (MHz)	5.5
Slew rate (typ) (V/µs)	8
Vos (offset voltage at 25°C) (max) (mV)	10
Offset drift (typ) (V/°C)	0.000025
Iq per channel (typ) (mA)	18
Features	Decompensated
Rating	Catalog
Operating temperature range (°C)	0 to 70
Input bias current (max) (pA)	2000000
CMRR (typ) (dB)	90
Rail-to-rail	No
Architecture	Bipolar
