Описание

This 27 mΩ, 20 V, P-Channel device is designed to deliver the lowest on-resistance and gate charge in a small 1.0 × 1.5 mm outline with excellent thermal characteristics in an ultra-low profile.

VDS (V)	-20
VGS (V)	-8
Configuration	Single
Rds(on) at VGS=4.5 V (max) (mΩ)	32.5
Rds(on) at VGS=2.5 V (max) (mΩ)	45.5
Rds(on) at VGS=1.8 V (max) (mΩ)	92
Id peak (max) (A)	-41
Id max cont (A)	-3
QG (typ) (nC)	3.3
QGD (typ) (nC)	0.5
QGS (typ) (nC)	0.7
VGSTH typ (typ) (V)	-0.8
ID - silicon limited at TC=25°C (A)	3
Logic level	Yes
Operating temperature range (°C)	-55 to 150
Rating	Catalog
