Описание

The ONET8501P is a high-speed, 3.3-V limiting amplifier for multiple fiber optic and copper cable applications with data rates from 2 Gbps up to 11.3 Gbps.The device provides a two-wire serial interface which allows digital control of the bandwidth, output amplitude, output pre-emphasis, input threshold voltage (slice level) and the loss of signal assert level. Predetermined settings for bandwidth and LOS assert levels can also be selected with external rate selection pins.The ONET8501P provides a gain of about 40dB which ensures a fully differential output swing for input signals as low as 10 mVpp. The output amplitude can be adjusted to 300 mVpp, 600 mVpp, or 900 mVpp. To compensate for frequency dependent loss of microstrips or striplines connected to the output of the device, programmable pre-emphasis is included in the output stage. A settable loss of signal detection and output disable are also provided.The part, available in RoHS compliant small footprint 3 mm × 3 mm 16-pin QFN package, typically dissipates less than 160 mW and is characterized for operation from -40°C to 100°C.

Up to 11.3-Gbps Operation
2-Wire Digital Interface
Digitally Selectable Input Bandwidth
Adjustable LOS Threshold
Digitally Selectable Output Voltage
Digitally Selectable Output Pre-Emphasis
Adjustable Input Threshold Voltage
Low Power Consumption
Input Offset Cancellation
CML Data Outputs with On-Chip 50- Back-Termination to VCC
Single +3.3-V Supply
Output Disable
Surface Mount Small Footprint 3 mm × 3 mm 16-Pin RoHS compliant QFN Package
APPLICATIONS
- 10-Gigabit Ethernet Optical Receivers
- 8x and 10x Fiber Channel Optical Receivers
- SONET OC-192/SDH-64 Optical Receivers
- SFP+ and XFP Transceiver Modules
- XENPAK, XPAK, X2 and 300-pin MSA Transponder Modules
- Cable Driver and Receiver

Type	Limiting amplifier
Data rate (max) (MBits)	11300
Features	Bandwidth select
Supply current (typ) (µA)	48000
Supply current (max) (µA)	61000
Deterministic jitter (typ) (ps)	4
Operating temperature range (°C)	-40 to 100
