Описание

The DS90LV027AH is a dual LVDS driver device optimized for high data rate and low power applications. The device is designed to support data rates in excess of 600Mbps (300MHz) utilizing Low Voltage Differential Signaling (LVDS) technology. The DS90LV027AH is a current mode driver allowing power dissipation to remain low even at high frequency. In addition, the short circuit fault current is also minimized. The device is in a 8-lead SOIC package. The DS90LV027AH has a flow-through design for easy PCB layout. The differential driver outputs provides low EMI with its typical low output swing of 360 mV. It is perfect for high speed transfer of clock and data. The DS90LV027AH can be paired with its companion dual line receiver, the DS90LV028AH, or with any of TIs LVDS receivers, to provide a high-speed point-to-point LVDS interface.

−40°C to +125°C Operating Temperature Range
>600-Mbps (300-MHz) Switching Rates
0.3-ns Typical Differential Skew
0.7-ns Maximum Differential Skew
3.3-V Power Supply Design
Low power dissipation (46 mW at 3.3-V Static)
Flow-Through Design Simplifies PCB Layout
Power Off Protection (Outputs in High Impedance)
Conforms to TIA/EIA-644 Standard
8-Pin SOIC Package Saves Space

Function	Driver
Protocols	LVDS
Number of transmitters	2
Number of receivers	0
Supply voltage (V)	3.3
Signaling rate (MBits)	600
Input signal	CMOS, TTL
Output signal	LVCMOS, LVTTL
Rating	Catalog
Operating temperature range (°C)	-40 to 125
