Описание

Wide operating voltage range of 2 V to 6 V
Low input current of 1 µA max
High-current outputs drive up to 10 LSTTL loads
Low power consumption, 40-µA max I_CC
Typical t_pd = 12 ns
±4-mA output drive at 5 V

Number of channels	2
Technology family	HC
Supply voltage (min) (V)	2
Supply voltage (max) (V)	6
Input type	CMOS
Output type	Push-Pull
Clock frequency (MHz)	20
Supply current (max) (µA)	80
IOL (max) (mA)	-4
IOH (max) (mA)	4
Features	Balanced outputs, Clear, High speed (tpd 10-50ns), Positive edge triggered, Positive input clamp diode, Preset
Operating temperature range (°C)	-55 to 125
Rating	Space
