Описание

Number of channels	2
Technology family	HC
Supply voltage (min) (V)	2
Supply voltage (max) (V)	6
Input type	LVTTL/CMOS
Output type	Push-Pull
Clock frequency (MHz)	24
Supply current (max) (µA)	40
IOL (max) (mA)	6
IOH (max) (mA)	-6
Features	Balanced outputs, Clear, High speed (tpd 10-50ns), Negative edge triggered, Positive input clamp diode, Preset
Operating temperature range (°C)	-55 to 125
Rating	Catalog
