Описание

The TPS92560 is a simple LED driver designed to drive high-power LEDs by drawing constant current from the power source. The device is ideal for MR16 and AR111 applications, which require good compatibility to DC and AC voltages and electronic transformers. The hysteretic control scheme does not need control loop compensation while providing the benefits of fast transient response and high power factor. The patent pending feedback control method allows the output power to be determined by the number of LED used without component change. The TPS92560 supports both boost and SEPIC configurations for the use of different LED modules.

Controlled peak input current to prevent over-
stressing of the electronic transformer
Allows Either Step-Up or Step-Up/Down Operation
Compatible to Generic Electronic Transformers
Compatible to Magnetic Transformers and DC
Power Supplies
Integrated Active Low-Side Input Rectifiers
Compact and Simple Circuit
>85% Dfficiency (12-VDC Input)
Power Factor > 0.9 (Full Load With AC input)
Hysteretic Control Scheme
Output Overvoltage Protection
Overtemperature Shutdown
10-pin Thermally Enhanced Very-Thin Fine Pitch
Small-Outline Package

Input voltage type	AC/DC, DC/DC
Topology	Boost, Buck-Boost, SEPIC
Vin (min) (V)	6.5
Vin (max) (V)	42
Vout (max) (V)	42
Vout (min) (V)	5
Iout (max) (A)	2
Iq (typ) (mA)	1.4
Features	Adjustable Switch Frequency, Thermal shutdown, Work with Electronic Transformer
Operating temperature range (°C)	-40 to 125
Dimming method	Analog
Number of channels	1
Rating	Catalog
