Описание

The LM36010 is an ultra-small LED flash driver that provides a high level of adjustability. With a total solution size of 7 mm2, it can produce up to 1.5 A of LED flash current or up to 376 mA of torch current. The device utilizes a 2-MHz or 4-MHz fixed-frequency, synchronous boost converter to power the 1.5-A constant current LED source. An adaptive regulation method ensures the current source remains in regulation and maximizes efficiency as it controls the current from 11 mA up to 1.5 A in flash mode or from 2.4 mA up to 376 mA in torch mode. Features of the LM36010 are controlled via an I2C-compatible interface. These features include: hardware flash (STROBE) and 128 programmable currents for both flash and movie mode (torch). The 2-MHz or 4-MHz switching frequency, overvoltage protection (OVP), and adjustable current limit allow for the use of tiny, low-profile inductors and ceramic capacitors. The device operates over a –40°C to +85°C ambient temperature range.

Accurate and Programmable LED Currents
- Flash / IR Currents Ranging from 11 mA up to 1.5 A (128 Levels)
- Torch Currents Ranging from 2.4 mA up to 376 mA (128 Levels)
Flash Time-Out up to 1.6 Seconds
Optimized Flash LED Current During Low Battery Conditions (IVFM)
Grounded Cathode LED Operation for Improved Thermal Management
Small Total Solution Size: < 7 mm²
Hardware Strobe Enable (STROBE)
Input Voltage Range from 2.5 V to 5.5 V
400-kHz I²C-Compatible Interface
- I²C Address = 0x64

Input voltage type	DC/DC
Topology	Boost, current mode
Vin (min) (V)	2.5
Vin (max) (V)	5.5
Vout (max) (V)	5.5
Vout (min) (V)	2.5
Iout (max) (A)	1.5
Iq (typ) (mA)	0.3
Features	I2C control, IR Mode, OVP, Synchronous Rectification
Operating temperature range (°C)	-40 to 85
Dimming method	Analog, PWM
Number of channels	1
Rating	Catalog
