Описание

The TLV9051, TLV9052, and TLV9054 devices are single, dual, and quad operational amplifiers, respectively. The devices are designed for low voltage operation from 1.8 V to 6.0 V. The inputs and outputs can operate from rail to rail at a very high slew rate. These devices are an excellent choice for cost-constrained applications where low-voltage operation, high slew rate, and low quiescent current is needed. The capacitive-load drive of the TLV905x family is 150 pF, and the resistive open-loop output impedance makes stabilization easier with much higher capacitive loads.The TLV905xS devices include a shutdown mode that allow the amplifiers to be switched off into a standby mode with typical current consumption less than 1 µA.The TLV905x family is easy to use due to the devices being unity-gain stable, including a RFI and EMI filter, and being free from phase reversal in an overdrive condition.

High slew rate: 15 V/µs
Low quiescent current: 330 µA
Rail-to-rail input and output
Low input offset voltage: ±0.33 mV
Unity-gain bandwidth: 5 MHz
Low broadband noise: 15 nV/√ Hz
Low input bias current: 2 pA
Unity-gain stable
Internal RFI and EMI filter
Scalable family of CMOS op amps for low-cost applications
Operational at supply voltages as low as 1.8 V
Extended temperature range: –40°C to 125°C

Number of channels	1
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	5.5
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	1.8
Rail-to-rail	In, Out
GBW (typ) (MHz)	5
Slew rate (typ) (V/µs)	15
Vos (offset voltage at 25°C) (max) (mV)	1.6
Iq per channel (typ) (mA)	0.33
Vn at 1 kHz (typ) (nV√Hz)	20
Rating	Catalog
Operating temperature range (°C)	-40 to 125
Offset drift (typ) (µV/°C)	0.5
Features	Cost Optimized, EMI Hardened, Shutdown, Small Size
CMRR (typ) (dB)	96
Iout (typ) (A)	0.05
Architecture	CMOS
Input common mode headroom (to negative supply) (typ) (V)	-0.1
Input common mode headroom (to positive supply) (typ) (V)	0.1
Output swing headroom (to negative supply) (typ) (V)	0.03
Output swing headroom (to positive supply) (typ) (V)	-0.03
