Описание

The DS90UB934-Q1 FPD-Link III deserializer, in conjunction with the DS90UB913A/933-Q1 serializers, supports the video transport needs with an ultra-high-speed forward channel and an embedded bidirectional control channel. The DS90UB934-Q1 converts the FPD-Link III stream into a parallel CMOS output interface designed to support automotive image sensors up to 12 bits at 100 MHz with resolutions including 1MP/60fps and 2MP/30fps.The DS90UB933/934 chipset is fully AEC-Q100 qualified and designed to receive data across either 50-Ω single-ended coaxial or 100-Ω shielded-twisted pair (STP) cable assemblies. The DS90UB934-Q1 uses an advanced adaptive equalizer to allow support of various cable lengths and types with no additional programming required.The DS90UB934-Q1 is improved over prior generations of ADAS FPD-Link III deserializer devices (such as DS90UB914A-Q1) offering higher bandwidth support with additional enhancements.

Qualified for automotive applications
AEC-Q100 qualified for automotive applications with the following results:
- Device temperature grade 2: –40°C to +105°C ambient operating temperature
- Device HBM ESD classification level ±2 kV
- Device CDM ESD classification level C4
Operates up to 100 MHz in 12-bit mode to support 1 MP/60 fps and 2 MP/30 fps imagers as well as satellite RADAR
Configurable 12-bit parallel CMOS compatible with DS90UB913A/933 serializers
Adaptive equalization compensates for cable aging and degradation effects
Ultra-low latency bi-directional control data channel with data protection
Cable link detect diagnostics
Supports Power-over-Coax operation (PoC)
ISO 10605 and IEC 61000-4-2 ESD compliant
Low radiated and conductive emissions
BIST (Built-In Self-Test)

Function	Deserializer
Color depth (bps)	12
Input compatibility	FPD-Link III LVDS
Pixel clock frequency (max) (MHz)	100
Output compatibility	LVCMOS
Features	Low-EMI Point-to-Point Communication
Signal conditioning	Adaptive Equalizer
EMI reduction	BIST
Diagnostics	BIST
Rating	Automotive
Operating temperature range (°C)	-40 to 105
