Описание

The number of applications requiring Ethernet connectivity continues to increase. Along with this increased market demand is a change in application requirements. The DP83848-EP was designed to allow Ethernet connectivity in the harshest environments. Our device meets IEEE 802.3u standards over a military temperature range of –55°C to 125°C. This device is ideally suited for harsh environments for example avionics, defense and industrial control applications.The DP83848-EP is a highly reliable, feature rich robust device which includes enhanced ESD protection, MII, and RMII for maximum flexibility in MPU selection all in a 48-pin PQFP package.The DP83848-EP features integrated sublayers to support both 10BASE-T and 100BASE-TX Ethernet protocols, which ensures compatibility and interoperability with all other standards based Ethernet solutions.

Low-power 3.3-V, 0.18-µm CMOS technology
Low-power consumption < 270-mW typical
3.3-V MAC interface
Auto-MDIX for 10/100 Mbps
Energy detection mode
25-MHz clock out
SNI interface (configurable)
RMII rev. 1.2 interface (configurable)
MII serial management interface (MDC and MDIO)
IEEE 802.3u MII
IEEE 802.3u auto-negotiation and parallel detection
IEEE 802.3u ENDEC, 10BASE-T transceivers and filters
IEEE 802.3u PCS, 100BASE-TX transceivers and filters
IEEE 1149.1 JTAG
Integrated ANSI X3.263 compliant TP-PMD physical sublayer with adaptive equalization and baseline wander compensation
Error-free operation up to 150 m
Programmable LED support link, 10/100 Mbps mode, activity, and collision detect
Single register access for complete PHY status
10/100 Mbps packet BIST (built in self test)
Lead-free 48-pin PQFP packages 7 mm × 7 mm

Datarate (Mbps)	10/100
Interface type	MII, RMII, SNI
Number of ports	Single
Rating	HiRel Enhanced Product
Features	JTAG1149.1
Supply voltage (V)	3.3
I/O supply voltage (typ) (V)	3.3
Operating temperature range (°C)	-55 to 125
Number of LEDs	3
ESD HBM (kV)	4
