Описание

The TPS2662x family are compact, feature rich high voltage eFuses with a full suite of protection features. The wide supply input range of 4.5 V to 60 V allows control of many popular DC bus voltages. The device can withstand and protect the loads from positive and negative supply voltages up to ±60 V. The TPS26624 and TPS26625 devices support both input as well as output reverse polarity protection feature. Integrated back to back FETs provide reverse current blocking feature making the device suitable for systems with output voltage holdup requirements during power fail and brownout conditions. Load, source and device protection are provided with many adjustable features including overcurrent, output slew rate and overvoltage, undervoltage thresholds. The internal robust protection control blocks along with the high voltage rating of the TPS2662x family helps to simplify the system designs for Surge protection.The TPS26620, TPS26622 and TPS26624 feature latch-off and TPS26621, TPS26623 and TPS26625 feature auto-retry functionality, which are the overtemperature and overcurrent fault events.The devices are available in a 3 mm × 3 mm 10-pin SON package and are specified over a –40°C to +125°C temperature range.

4.5-V to 60-V operating voltage, 62-V absolute maximum
Integrated reverse input polarity protection to –60 V
Integrated reverse output polarity protection to – (60 – V_IN) (TPS26624 and TPS26625 only)
Integrated back to back MOSFETs with 478-mΩ total RON
25-mA to 880-mA adjustable current limit (±5% accuracy at 880 mA)
Load protection during surge (IEC 61000-4-5) with minimum external components
Electrical fast transients immunity according to IEC 61000-4-4
Fast reverse current blocking response (0.3 µs)
Adjustable UVLO, OVP cut off, output slew rate control for inrush current limiting
Fixed 38-V overvoltage clamp (TPS26622 and TPS26623 only)
Low quiescent current, 340 µA in operating, 12 µA in shutdown
Small foot print – 10L (3 mm × 3 mm) VSON
UL 2367 recognized
- File No. 169910
- R_ILIM ≥ 7.5 kΩ (0.91-A maximum )
IEC 62368-1 certified

FET	Internal
Ron (typ) (mΩ)	478
Vin (min) (V)	4.5
Vin (max) (V)	60
Vabsmax_cont (V)	62
Current limit (min) (A)	0.025
Current limit (max) (A)	0.88
Overcurrent response	Circuit breaker, Current limiting
Soft start	Adjustable
Overvoltage response	Clamp, Cut-off
UL recognition	IEC62368, UL2367
Rating	Catalog
Device type	eFuses and hot swap controllers
Operating temperature range (°C)	-40 to 125
Function	Adjustable current limit, Current monitoring, Inrush current control, Overvoltage protection, Power good signal, Reverse current blocking, Reverse polarity protection, Short circuit protection, Thermal shutdown
