Описание

The TMP107 digital output temperature sensor supports a total of 32 daisy-chained devices. Each sensor has a unique 5-bit address stored in electrically-erasable programmable memory (EEPROM). The TMP107 is capable of reading temperatures with a resolution of 0.015625°C, and is accurate to within ±0.4°C in the range from –20°C to +70°C. The TMP107 is ideal for replacing NTC and PTC thermistors where high accuracy is required.The unique 5-bit address stored in the EEPROM is determined during the automated address assignment operation, and is based on the position of each sensor relative to the SMAART wire host. Multiple operating modes provide maximum flexibility in selecting between low power consumption for battery operation, and high update rates for real-time control applications. The TMP107 is ideal for extended temperature measurement in a variety of industrial, instrumentation, communication, and environmental applications. The TMP107 is available in an 8-pin SOIC package and is specified for operation over a temperature range of −55°C to +125°C.

High Accuracy (Without Calibration):
- ±0.4°C (max) from –20°C to +70°C
- ±0.55°C (max) from –40°C to +100°C
- ±0.7°C (max) from –55°C to +125°C
High Resolution: 14 Bits (0.015625°C)
UART-Compatible, SMAART Wire™ Interface:
- Allows Up To 32 Daisy-Chained Devices
EEPROM Memory for Unique Addressing, Trip Level Programming, and General-Purpose Storage
Continuous Conversion and Shutdown Mode for Power Savings
One-Shot Conversion Mode for Custom Update Rates and Power Savings
Programmable Alert Feature
Operating Temperature Range: –55°C to +125°C
Operating Supply Range: 1.7 V to 5.5 V
Package: SOIC-8

Local sensor accuracy (max)	0.4
Type	Local
Operating temperature range (°C)	-55 to 125
Supply voltage (min) (V)	1.7
Interface type	UART
Supply voltage (max) (V)	5.5
Features	ALERT, Daisy chain, EEPROM, One-shot conversion
Supply current (max) (µA)	35
Temp resolution (max) (Bits)	14
Remote channels (#)	0
Addresses	32
Rating	Catalog
