Описание

The AUP family is TI's premier solution to the industry's low-power needs in battery-powered portable applications. This family ensures a very low static- and dynamic-power consumption across the entire VCC range of 0.8 V to 3.6 V, resulting in increased battery life. This product also maintains excellent signal integrity (see the very low undershoot and overshoot characteristics shown in ).

Available in the Texas Instruments NanoStar Package

Low Static-Power Consumption: I_CC = 0.9 μA Maximum

Low Dynamic-Power Consumption: C_pd = 5.5 pF Typical at 3.3 V

Low Input Capacitance: C_i = 1.5 pF Typical

Low Noise – Overshoot and Undershoot < 10% of V_CC

I_off Supports Partial-Power-Down Mode Operation

Schmitt-Trigger Action Allows Slow Input Transition and Better Switching Noise Immunity at the Input (V_hys = 250 mV Typical at 3.3 V)

Wide Operating V_CC Range of 0.8 V to 3.6 V

Optimized for 3.3-V Operation

3.6-V I/O Tolerant to Support Mixed-Mode Signal Operation

t_pd = 5 ns Maximum at 3.3 V

Suitable for Point-to-Point Applications

Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II

ESD Performance Tested Per JESD 22

2000-V Human-Body Model (A114-B, Class II)
1000-V Charged-Device Model (C101)

NanoStar Is a trademark of Texas Instruments. All other trademarks are the property of their respective owners

APPLICATIONS

Number of channels	1
Technology family	AUP
Supply voltage (min) (V)	0.8
Supply voltage (max) (V)	3.6
Input type	Standard CMOS
Output type	Push-Pull
Clock frequency (max) (MHz)	160
IOL (max) (mA)	4
IOH (max) (mA)	-4
Supply current (max) (µA)	0.9
Features	Balanced outputs, Over-voltage tolerant inputs, Partial power down (Ioff), Very high speed (tpd 5-10ns)
Operating temperature range (°C)	-40 to 85
Rating	Catalog
