Описание

The LMK02000 precision clock conditioner combines the functions of jitter cleaning/reconditioning, multiplication, and distribution of a reference clock. The device integrates a high performance Integer-N Phase Locked Loop (PLL), three LVDS, and five LVPECL clock output distribution blocks.Each clock distribution block includes a programmable divider, a phase synchronization circuit, a programmable delay, a clock output mux, and an LVDS or LVPECL output buffer. This allows multiple integer-related and phase-adjusted copies of the reference to be distributed to eight system components.The clock conditioner comes in a 48-pin WQFN package and is footprint compatible with other clocking devices in the same family.

20 fs Additive Jitter
Integrated Integer-N PLL with Outstanding Normalized Phase Noise Contribution of -224 dBc/Hz
Clock Output Frequency Range of 1 to 800 MHz
3 LVDS and 5 LVPECL Clock Outputs
Dedicated Divider and Delay Blocks on Each Clock Output
Pin Compatible Family of Clocking Devices
3.15 to 3.45 V Operation
Package: 48 Pin WQFN (7.0 x 7.0 x 0.8 mm)

Function	Clock generator
Number of outputs	8
Output frequency (max) (MHz)	800
Core supply voltage (V)	3.3
Output supply voltage (V)	3.3
Input type	LVCMOS, LVPECL
Output type	LVDS
Operating temperature range (°C)	-40 to 85
Features	Integrated integer-N PLL, uWire
Rating	Catalog
