Описание

The BQ40Z50-R2 device, incorporating patented Impedance Track™ technology, is a fully integrated, single-chip, pack-based solution that provides a rich array of features for gas gauging, protection, and authentication for 1-series, 2-series, 3-series, and 4-series cell Li-ion and Li-polymer battery packs.Using its integrated high-performance analog peripherals, the BQ40Z50-R2 device measures and maintains an accurate record of available capacity, voltage, current, temperature, and other critical parameters in Li-ion or Li-polymer batteries, and reports this information to the system host controller over an SMBus v1.1 compatible interface.

Fully integrated 1-series, 2-series, 3-series, and 4-series Li-ion or Li-polymer cell battery pack manager and protection
Next-generation patented Impedance Track™ technology accurately measures available charge in Li-ion and Li-polymer batteries
High-side N-CH protection FET drive
Integrated cell balancing while charging or at rest
Suitable for batteries between 100 mAh and 29 Ah
Full array of programmable protection features
- Voltage
- Current
- Temperature
- Charge timeout
- CHG/DSG FETs
- AFE
Sophisticated charge algorithms
- JEITA
- Enhanced charging
- Adaptive charging
- Cell balancing
Supports TURBO Mode 2.0
Supports battery trip point (BTP)
Diagnostic lifetime data monitor and black box recorder
LED display
Supports two-wire SMBus v1.1 interface
SHA-1 authentication
IATA support
Compact package: 32-lead QFN (RSM)

Cell chemistry	Li-Ion/Li-Polymer, LiFePO4
Number of series cells	2-4 Cells, Single Cell
Communication interface	SMBus
Battery capacity (min) (mAh)	100
Battery capacity (max) (mAh)	65000
Implementation	Pack
External capacity indication	LED
Features	Cell balancing, Impedance Track™ algorithm, Integrated Protector, SHA-1 Authentication, Turbo Mode
Operating temperature range (°C)	-40 to 85
Cell balancing	External, Internal
Rating	Catalog
