Описание

The OPA169x operational amplifiers achieve a new level of performance for low-power amplifiers with a low 4.2-nV/√Hz noise density and distortion of –127 dB at 1 kHz. This op amps offer rail-to-rail output swing to within 200 mV of the power supplies with a 2-kΩ load, which increases headroom and maximizes dynamic range. These devices have a high output drive capability of ±50 mA.The OPA169x operational amplifiers operate over a wide supply range of ±1.75 V to ±18 V, or 3.5 V to 36 V (on 650 µA of supply current per channel), are unity-gain stable, and provide excellent dynamic behavior over a wide range of load conditions.The OPA169x op amps are specified for a temperature range of –40°C to 125°C.

Low Noise: 4.2 nV/√Hz at 1 kHz
Low Distortion: –127 dB at 1 kHz
Low Quiescent Current:
650 µA per Channel
Slew Rate: 23 V/µs
Wide Gain Bandwidth: 5.1 MHz
Unity-Gain Stable
Rail-to-Rail Output
Wide Supply Range:
±1.75 V to ±18 V, or 3.5 V to 36 V

Number of channels	2
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	36
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	3.5
Vos (offset voltage at 25°C) (max) (mV)	0.8
GBW (typ) (MHz)	5.1
Features	Burr-Brown™ Audio
Slew rate (typ) (V/µs)	23
Rail-to-rail	Out
Offset drift (typ) (µV/°C)	0.5
Iq per channel (typ) (mA)	0.65
Vn at 1 kHz (typ) (nV√Hz)	4.2
CMRR (typ) (dB)	140
Rating	Catalog
Operating temperature range (°C)	-40 to 125
Input bias current (max) (pA)	550000
Iout (typ) (A)	0.05
Architecture	Bipolar
Input common mode headroom (to negative supply) (typ) (V)	1.5
Input common mode headroom (to positive supply) (typ) (V)	-0.5
Output swing headroom (to negative supply) (typ) (V)	0.2
Output swing headroom (to positive supply) (typ) (V)	-0.2
THD + N at 1 kHz (typ) (%)	0.000045
