Описание

The OPA1612-Q1 device is a dual, SoundPlus, bipolar-input operational amplifierthat achieves achieve very low 1.1-nV/√Hz noise density with an ultralow distortion of 0.000015% at 1 kHz. The OPA1612-Q1 device offers rail-to-rail output swing to within 600 mV with a 2-kΩ load, which increases headroom and maximizes dynamic range. These devices also have a high output drive capability of ±30 mA. These devices operate over a very wide supply range of ±2.25 V to ±18 V, on only 3.6 mA of supply current per channel. The OPA1612-Q1 op amp is unity-gain stable and provide excellent dynamic behavior over a wide range of load conditions. The dual version features completely independent circuitry for lowest crosstalk and freedom from interactions between channels, even when overdriven or overloaded. The OPA1612-Q1 device is available in a SOIC-8 package. The device is specified from –40°C to +125°C. For all available packages, see the orderable addendum at the end of the datasheet.

Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
- Device Temperature Grade 1: –40°C to +125°C Ambient Operating Temperature Range
- Device HBM Classification Level 2
- Device CDM Classification Level C6
Superior Sound Quality
Ultralow Noise: 1.1 nV/√Hz at 1 kHz
Ultralow Distortion:
0.000015% at 1 kHz
High Slew Rate: 27 V/μs
Wide Bandwidth: 40 MHz (G = +1)
High Open-Loop Gain: 130 dB
Unity Gain Stable
Low Quiescent Current:
3.6 mA per Channel
Rail-to-Rail Output
Wide Supply Range: ±2.25 V to ±18 V

Number of channels	2
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	4.5
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	36
GBW (typ) (MHz)	40
Slew rate (typ) (V/µs)	27
Rail-to-rail	Out
Vos (offset voltage at 25°C) (max) (mV)	0.5
Iq per channel (typ) (mA)	3.6
Vn at 1 kHz (typ) (nV√Hz)	1.1
THD + N at 1 kHz (typ) (%)	0.000015
Rating	Automotive
Operating temperature range (°C)	-40 to 125
Iout (typ) (A)	0.055
Architecture	Bipolar
CMRR (typ) (dB)	120
Input bias current (max) (pA)	250000
