Описание

The LME49724 is an ultra-low distortion, low noise, high slew rate fully-differential operational amplifier optimized and fully specified for high performance, high fidelity applications. Combining advanced leading-edge process technology with state of the art circuit design, the LME49724 fully-differential audio operational amplifier delivers superior audio signal amplification for outstanding audio performance. The LME49724 combines extremely low voltage noise density (2.1nV/√Hz) with vanishingly low THD+N (0.00003%) to easily satisfy the most demanding audio applications. To ensure that the most challenging loads are driven without compromise, the LME49724 has a high slew rate of ±18V/μs and an output current capability of ±80mA. Further, dynamic range is maximized by an output stage that drives 600Ω loads to 52VP-P while operating on a ±15V supply voltage. The LME49724's outstanding CMRR (102dB), PSRR (125dB), and VOS (0.2mV) results in excellent operational amplifier DC performance. The LME49724 has a wide supply range of ±2.5V to ±18V. Over this supply range the LME49724’s input circuitry maintains excellent common-mode and power supply rejection, as well as maintaining its low input bias current. The LME49724 is unity gain stable. This Fully-Differential Audio Operational Amplifier achieves outstanding AC performance while driving complex loads with capacitive values as high as 100pF.

Drives 600Ω Loads with Full Output Signal Swing
Optimized for Superior Audio Signal Fidelity
Output Short Circuit Protection
PSRR and CMRR Exceed 100dB (typ)
Available in SO PowerPad Package

All trademarks are the property of their respective owners.

Number of channels	1
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V)	5
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V)	36
GBW (typ) (MHz)	50
Slew rate (typ) (V/µs)	18
Rail-to-rail	No
Vos (offset voltage at 25°C) (max) (mV)	1
Iq per channel (typ) (mA)	10
Vn at 1 kHz (typ) (nV√Hz)	2.1
Features	Shutdown
THD + N at 1 kHz (typ) (%)	0.00003
Rating	Catalog
Operating temperature range (°C)	-40 to 85
Iout (typ) (A)	0.08
Architecture	Voltage FB
CMRR (typ) (dB)	102
Input bias current (max) (pA)	200000
