Описание

The TLV320DAC3203 (sometimes referred to as the DAC3203) is a flexible, low-power, low-voltage stereo audio codec with programmable outputs, PowerTune capabilities, fixed predefined and parameterizable signal processing blocks, integrated PLL, integrated LDO and flexible digital interfaces. Extensive register-based control of power, input/output channel configuration, gains, effects, pin-multiplexing and clocks is included, allowing the device to be precisely targeted to its application.The device is available in the 4 mm × 4 mm VQFN and 2.7 mm × 2.7 mm DSGBA package.

Stereo Audio DAC with 100dB SNR
4.1mW Stereo 48ksps Playback
PowerTune™
Extensive Signal Processing Options
Stereo Headphone Outputs
Low Power Analog Bypass Mode
Programmable PLL
Integrated LDO
4 mm × 4 mm VQFN and 2.7 mm × 2.7 mm DSGBA Package

Sampling rate (max) (kHz)	192
Control interface	SPI
Architecture	Class-AB
Operating temperature range (°C)	-40 to 85
Rating	Catalog
