Описание

The PCM3070 is a flexible stereo audio codec with programmable inputs and outputs, fully-programmable miniDSP, fixed predefined and parameterizable signal processing blocks, integrated PLL, integrated LDOs and flexible digital interfaces.

Stereo Audio DAC with 100dB SNR
Stereo Audio ADC with 93dB SNR
Extensive Signal Processing Options
Embedded miniDSP
Six Single-Ended or 3 Fully-Differential
Analog Inputs
Stereo Headphone Outputs
Stereo Line Outputs
Very Low-Noise PGA
Analog Bypass Mode
Programmable PLL
Integrated LDO
5 mm × 5 mm 32-Pin QFN Package

Number of ADC channels	2
Number of DAC channels	2
Digital audio interface	DSP, I2S, L, R, TDM
Analog inputs	6
Analog outputs	4
Sampling rate (max) (kHz)	192
Rating	Catalog
Features	MiniDSP, Phase-locked loop (PLL), Stereo headphone amplifier
ADC SNR (typ) (dB)	93
DAC SNR (typ) (dB)	100
Operating temperature range (°C)	-40 to 85
