Описание

The TI DLP650NE digital micromirror device (DMD) is a digitally controlled micro-electromechanical system (MEMS) spatial light modulator (SLM) that enables bright, affordable DLP 0.65 1080p display solutions. The DLP650NE DMD—together with the DLPC4430 display controller and the DLPA100 power manager and motor driver—provides the capability to achieve high performance systems, and is a great fit for display applications that require high resolution and 16:9 aspect ratio, high brightness, and system simplicity. .

0.65-inch micromirror array diagonal
- 1080p (1920 × 1080)
- 7.56-micron micromirror pitch
- ± 12° micromirror tilt angle (relative to flat state)
- Corner illumination
2xLVDS input data bus
The DLP650NE chipset includes:

Component type	DMD
Display resolution (max)	1080p (1920x1080)
Chipset family	DLPC4430
Array diagonal (in)	0.65
Input frame rate (max) (Hz)	120
Rating	Catalog
Micromirror array size	1920x1080
Micromirror pitch (mm)	0.0076
Operating temperature range (°C)	0 to 70
