Описание

The DLP3310 digital micromirror device (DMD) is a digitally controlled micro-opto-electromechanical system (MOEMS) spatial light modulator (SLM). When coupled with an appropriate optical system, the DLP3310 DMD displays a very crisp and high quality image or video. DLP3310 is part of the chipset composed of the DLP3310 DMD, DLPC3437 controller, and DLPA3000/DLPA3005 PMIC/LED driver. The compact physical size of the DLP3310 coupled with the controller and the PMIC/LED driver provides a complete system solution that enables small form factor, low power, and full-HD displays.Visit the getting started with TI DLP® Pico™ display technology page to learn how to get started with the DLP3310.The DLP3310 ecosystem includes established resources to help the user accelerate the design cycle, which include production ready optical modules, optical modules manufactures, and design houses.

0.33-inch (8.47-mm) diagonal micromirror array
- Displays full-HD 1920 × 1080 pixels on the screen
- 5.4-µm micromirror pitch
- 17° micromirror tilt (relative to flat surface)
- Side illumination for optimal efficiency and optical engine size
- Polarization independent aluminum micromirror surface
32-bit subLVDS input data bus
Dedicated DLPC3437 controller and DLPA3000/DLPA3005 PMIC/LED driver for reliable operation

Component type	DMD
Display resolution (max)	1080p (1920x1080)
Chipset family	DLP3310, DLPA3000, DLPA3005, DLPC3437
Array diagonal (in)	0.33
Input frame rate (max) (Hz)	60
Rating	Catalog
Micromirror array size	1368x768
Operating temperature range (°C)	0 to 70
