Описание

The DLP230NP and DLP230NPSE .23 1080p digital micromirror devices (DMD) are digitally controlled micro-opto-electromechanical systems (MOEMS) spatial light modulators (SLM). When coupled with an appropriate optical system, the DMDs display a crisp and high-quality 1080p image or video. The chipset contains the .23 1080p DMD and the DLPC3436 or DLPC3426 controller. The DLPA2000, DLPA2005, DLPA3000, and DLPA3005 PMIC/LED drivers support the DLP230NP chipset; the DLPA3000 driver supports the DLP230NPSE chipset. The compact physical size of the device applies to portable equipment where high image quality, small form factor, and low power are important.

Ultra-compact 0.23-inch (5.95-mm) diagonal micromirror array
- Displays 1920 × 1080 pixels on the screen
- 5.4 µm micromirror pitch
- 17° micromirror tilt (relative to flat surface)
- Side illumination for optimal efficiency and optical engine size
- Polarization independent aluminum micromirror surface
8-bit SubLVDS input data bus
Dedicated DLPC34x6 controller for display applications
Dedicated DLPA2000, DLPA2005, DLPA3000,or DLPA3005 PMIC/LED driver for reliable operation

Component type	DMD
Display resolution (max)	1080p (1920x1080)
Chipset family	DLP230NP, DLPA2000, DLPA2005, DLPA3000, DLPC3436
Array diagonal (in)	0.23
Input frame rate (max) (Hz)	60
Rating	Catalog
Micromirror array size	960x540
Micromirror pitch (mm)	0.0054
Operating temperature range (°C)	0 to 70
