Описание

The DLP2010 digital micromirror device (DMD) is a digitally controlled micro-opto-electromechanical system (MOEMS) spatial light modulator (SLM). When coupled to an appropriate optical system, this DMD is capable of displaying images, video, and patterns. This device is a component of the chipset that includes the DLP2010 DMD, DLPC3430 or DLPC3435 controller and DLPA200x/ DLPA3000 PMIC/LED driver. The compact physical size of this DMD can be used in portable equipment where small form factor and low power is important. The compact package compliments the small size of the LEDs for space-constrained light engines.Visit the getting started with TI DLP®PicoTM display technology page to learn how to get started with the DLP2010.The ecosystem includes established resources to help the user accelerate the design cycle, which include production ready optical modules, optical modules manufactures, and design houses.

0.2-Inch (5.29-mm) diagonal micromirror array
- Displays 854 × 480 pixel array, in an orthogonal layout
- 5.4-micron micromirror pitch
- ±17° micromirror tilt (relative to flat surface)
- Side illumination for optimal efficiency and optical engine size
- Polarization-independent aluminum micromirror surface
4-Bit SubLVDS input data bus
Dedicated DLPC3430, or DLPC3435 display controllers and DLPA200x/DLPA3000 PMIC and LED driver for reliable operation

Component type	DMD
Display resolution (max)	WVGA (854x480)
Chipset family	DLP2010, DLPA2000, DLPA2005, DLPA3000, DLPC3430, DLPC3435
Array diagonal (in)	0.2
Input frame rate (max) (Hz)	120
Rating	Catalog
Micromirror array size	854x480
Operating temperature range (°C)	0 to 70
